4.3-10 Male straight connector clamp type for 7/8 cable Tri-alloy plating PIM -160dBc
Interface
Electrical
| 1 | Characteristic Impedance | 50ohm |
| 2 | Frequency Range | DC-3GHz |
| 3 | VSWR | (DC-3GHz)≤1.12 |
| 4 | Dielectric withstanding voltage | ≥2500RMS,50Hz,at sea level |
| 5 | Dielectric Resistance | ≥5000MΩ |
| 6 | Contact Resistance | Outer Contact≤1.0mΩ ;Center Contact≤1.0mΩ |
| 7 | Insert Loss | ≤0.0.05dB |
| 8 | PIM ( @2-tonex20w) | ≤-160dBC |
| | | |
Mechanical
| Durability | Mating cycles ≥500 |
| | |
Material and plating
| | Description | Material | Plating |
| 1 | Body | Brass | Tri-alloy |
| 2 | Insulator | PTFE | – |
| 3 | Center conductor | Phosphor bronze | Ag |
| 4 | Gasket | Silicone rubber | - |
| 5 | Other | Brass | Ni |
| | | | |
Environmental
| 1 | Temperature Range | -40℃~+85℃ |
| 2 | Watertightness | IP67 |
| 3 | Rosh-compliance | Full ROHS compliance |
| 4 | Salt spraying test | 96h |
| | | |
